*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Mazak |
| Model: | FJV-35/60 |
| Condition: | Used |
| Equipped With: |
|---|
| MAZATROL SmoothG CNC Control |
| Rigid High-Speed Vertical Machining Design |
| Automatic Tool Changer |
| Linear Roller Guideways |
| Spindle Chiller |
| Coolant System |
| Full Enclosure |
| Work Light |
| Travels: |
|---|
| X-Axis Travel: 55.1″ |
| Y-Axis Travel: 35.4″ |
| Z-Axis Travel: 33.5″ |
| Spindle Nose to Table: 6.3″ – 39.4″ |
| Table: |
|---|
| Table Size: 60.0″ × 35.4″ |
| Max Table Load: 3,300 lbs |
| Spindle: |
|---|
| Spindle Taper: CAT-40 |
| Spindle Speed: 12,000 RPM |
| Spindle Motor: 30 HP |
| Direct-Drive Spindle |
| Feedrates: |
|---|
| Rapid Traverse X/Y/Z: 1,969 IPM |
| Cutting Feedrate: 0 – 787 IPM |
| Automatic Tool Changer: |
|---|
| Tool Capacity: 30 Tools |
| Max Tool Diameter: 3.15″ (6.3″ Adjacent Empty) |
| Max Tool Length: 11.8″ |
| Max Tool Weight: 17.6 lbs |
| General: |
|---|
| Power Requirement: 220V / 3-Phase |
| Machine Dimensions (Approx.): 170″ × 135″ × 130″ |
| Machine Weight (Approx.): 26,500 lbs |
