*All specifications are approximations and are subject to verification. Comes as shown in the images. Please call us if you have any questions before making a purchase. All sales are final.*
| Make: | Mazak |
| Model: | Quick Turn 350 |
| Condition: | Used |
| Capacity: |
|---|
- Maximum Swing (350): 26.77″
- Maximum Swing (M / MY / MSY): 29.5″
- Maximum Bar Capacity: 4.0″
- Max Turning Diameter: 16.5″
- Max Turning Diameter (MSY): 18.0″
- Max Turning Length (26″ Bed): 23.8″ – 25.7″
- Max Turning Length (60″ Bed): 60.7″ – 62.4″
- Max Turning Length (80″ Bed, MY): 81.1″
|
| Main Spindle: |
|---|
- Chuck Size: 12″
- Max Spindle Speed: 3,330 RPM
- Spindle Motor: 40 HP (30-Minute Rating)
- Spindle Type: Built-In Motor, Beltless
- C-Axis Indexing: 0.0001° (With Milling Option)
|
| Second Spindle (350MSY): |
|---|
- Chuck Size: 10″
- Max Spindle Speed: 4,000 RPM
- Spindle Motor: 35 HP (25% ED)
- DONE-IN-ONE® Machining Capability
|
| Turret & Milling: |
|---|
- Turret Type: 12-Station Drum Turret
- Turret Mount: VDI or Bolt-On
- Milling Capability: Available (M / MY / MSY)
- Milling Spindle Speed: 6,000 RPM (ER) / 4,000 RPM (CAT40)
- Milling Motor: 10 HP
- Live Tooling: Yes
|
| Axis Travels: |
|---|
- X-Axis Travel (350 / M / MY): 10.12″
- X-Axis Travel (MSY): 11.0″
- Y-Axis Travel (MY / MSY): ±3.0″
- Z-Axis Travel (26″ Bed): 26.3″
- Z-Axis Travel (60″ Bed): 63.2″
- Z-Axis Travel (80″ Bed): 83.5″
|
| Construction & Accuracy: |
|---|
- High-Rigidity Cast Machine Base
- Roller Linear Guides on All Axes
- Thermal Displacement Control (HD1 / HD2)
- Optional Linear Scales
- Temperature-Controlled Coolant System
|
| Automation & Options: |
|---|
- Bar Feeder Interface
- Auto Parts Catcher (Optional)
- Gantry / Robot Automation Ready
- TURN ASSIST System (Optional)
- Servo-Driven CNC Tailstock
- Steady Rest (Optional)
|
| Standard / Optional Equipment: |
|---|
- Tool Eye (Standard / Optional)
- High-Pressure Coolant – SUPERFLOW® (Optional)
- Mist Collector (Optional)
- Chip Conveyor (Optional)
- Automatic Doors (Optional)
- Workpiece Probe (Optional)
|
