*All specifications are approximations and are subject to verification. Comes as shown in the images. Please call us with any questions before purchasing. All sales are final.*
| Make: | Mori Seiki |
| Model: | SL-300BMC |
| Year: | 1998 |
| Machine Type: | CNC Slant Bed Lathe |
| Equipped With: |
|---|
| 10″ Chuck |
| Live Tooling |
| C-Axis |
| Tailstock |
| Hydraulic Tailstock |
| Chip Conveyor |
| Coolant System |
| Capacity: |
|---|
| Swing: 18.1″ |
| Maximum Turning Diameter: 16.5″ |
| Maximum Machining Length: 29.3″ |
| Bar Capacity: 3.5″ |
| Chuck Size: 10″ |
| Spindle Bore: 4.1″ |
| Center Distance: 29.3″ |
| Travels: |
|---|
| X-Axis Travel: 9.84″ |
| Z-Axis Travel: 31.5″ |
| Spindle: |
|---|
| Spindle Motor: 30 HP |
| Spindle Speed: 2,500 RPM |
| Spindle Nose: A2-8 |
| Spindle Bore: 4.1″ |
| Turret: |
|---|
| Turret Stations: 10 |
| Live Tool Speed: 4,500 RPM |
| Tailstock: |
|---|
| Type: Hydraulic |
| Quill Taper: MT-5 |
| Quill Diameter: 4.3″ |
| Quill Stroke: 5.9″ |
| General: |
|---|
| Power Source: 220V / 3-Phase / 60 Hz |
| Machine Dimensions (Approx.): 185″ L × 73″ W × 81″ H |
| Machine Weight (Approx.): 15,000 lbs. |
