*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Muratec |
| Model: | MW120 |
| Year: | 2014 |
| Equipped With: |
|---|
| Twin Spindle CNC Turning Center |
| Sub-Spindle for Complete Part Machining |
| C-Axis Capability on Main & Sub Spindles |
| Spindle Synchronization for Part Transfer |
| Rigid Tapping Capability |
| Automatic Central Lubrication System |
| Fully Enclosed Guarding with Safety Interlocks |
| Compact Production-Oriented Design |
| Automation & Bar Feeder Ready |
| Flood Coolant System |
| Integrated Chip Conveyor |
| Automatic Chip Discharge System |
| Travels: |
|---|
| X-Axis Travel: 5.90″ |
| Z-Axis Travel: 15.70″ |
| C-Axis: Main & Sub Spindles |
| Capacity: |
|---|
| Main Chuck: 6″ Hydraulic Chuck |
| Sub-Spindle Chuck: 6″ Hydraulic Chuck |
| Maximum Turning Diameter: 7.90″ |
| Maximum Turning Length: 12.00″ |
| Bar Capacity: 1.60″ |
| Spindles: |
|---|
| Configuration: Twin Spindle |
| Main Spindle Nose: A2-5 |
| Sub-Spindle Nose: A2-5 |
| Maximum Spindle Speed: 5,000 RPM |
| Spindle Motor Power: 10 HP – Main & Sub |
| Turret: |
|---|
| Turret Type: Servo-Driven Turret |
| Number of Stations: 12 |
| General: |
|---|
| Power Source: 220V / 3-Phase / 60 Hz |
| Machine Weight (Approx.): 8,000–9,000 lb |
