Sold
Daewoo Doosan DMV-4020S CNC Vertical Machining Center – 4th Axis Mill
Location
Lake Elsinore, CA
SKU
2381
Make/Model
DAEWOO DMV-4020S
Cutting Time
15,569 Hours
Video
On Request
Out of stock
Used Daewoo Doosan DMV-4020S Vertical Machining Center For Sale
| Location: | Lake Elsinore, CA |
| SKU: | 2381 |
| Make/Model: | DAEWOO DMV-4020S |
| Cutting Time: | 15,569 Hours |
| Video: | On Request |
Add to WishlistRemove from Wishlist
Add to Wishlist
*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | DAEWOO |
| Model: | DMV-4020S |
| Year: | 2002 |
| Condition: | Used – Good |
| Features: |
|---|
| Fanuc 18iM CNC Control |
| Box Way Construction |
| 4th Axis Rotary Table |
| 10000 RPM Precision Spindle |
| 30 Automatic high speed tool changer |
| Through Spindle coolant – 300 psi |
| PCMCIA Card Slot |
| MPG Control |
| Rigid Tapping |
| Spindle Orientation |
| Telescopic way covers |
| Spindle Chiller Unit |
| Flood Coolant system |
| Manuals & Books |
| Travels: |
|---|
| X-Axis: 40.2″ |
| Y-Axis: 20″ |
| Z-Axis: 20.2″ |
| Rapid Traverse Rates Axis: 1181 IPM |
| Cutting Feed Rates: 593 IPM |
| Spindle Nose to Table (Min.- Max.): 5.9″ – 26″ |
| Table: |
|---|
| Length: 47.2″ |
| Width: 19.7″ |
| Number of Std T-Slots: 5 |
| T-Slot Width: 5/8″ |
| Max Weight on Table: 1800 lbs |
| Spindle: |
|---|
| Taper Size: 40 |
| Speed Range: 10000 RPM |
| Spindle Power: 20 HP |
| Automatic Tool Changer: |
|---|
| Capacity: 30 Station Side Mounted |
| Max Tool Weight: 17.6 lbs |
| Max Tool Dia: 3″ -5.90″ |
| Max Tool Length: 11.81″ |
| Tool Changing Time : 1.5 Seconds |
| General: |
|---|
| Air Required: 80 psi 4 scfm |
| Power: 220v / 50.8 kva / 3-Phase |
| Overall Dimensions: 140″ x 100″ x 110″ High |
| Weight: 16500 lbs |
| Travels: |
|---|
| X-Axis: 1,021 mm |
| Y-Axis: 508 mm |
| Z-Axis: 513 mm |
| Rapid Traverse Rates Axis: 1181 IPM |
| Cutting Feed Rates: 593 IPM |
| Spindle Nose to Table (Min.- Max.): 150 mm - 660 mm |
| Table: |
|---|
| Length: 1,199 mm |
| Width: 500 mm |
| Number of Std T-Slots: 5 |
| T-Slot Width: 5/203 mm |
| Max Weight on Table: 1800 lbs |
| Spindle: |
|---|
| Taper Size: 40 |
| Speed Range: 10000 RPM |
| Spindle Power: 20 HP |
| Automatic Tool Changer: |
|---|
| Capacity: 30 Station Side Mounted |
| Max Tool Weight: 17.6 lbs |
| Max Tool Dia: 76 mm -150 mm |
| Max Tool Length: 300 mm |
| Tool Changing Time : 1.5 Seconds |
| General: |
|---|
| Air Required: 80 psi 4 scfm |
| Power: 220v / 50.8 kva / 3-Phase |
| Overall Dimensions: 3,556 mm x 2,540 mm x 2,794 mm High |
| Weight: 16500 lbs |
| Make | Daewoo Doosan |
|---|---|
| Model | DMV-4020S |
| Categories | Vertical Machining Center |
- Fanuc 18iM CNC Control
- Box Way Construction
- 4th Axis Rotary Table
- 10000 RPM Precision Spindle
- 30 Automatic high speed tool changer
- Through Spindle coolant - 300 psi
- PCMCIA Card Slot
- MPG Control
- Rigid Tapping
- Spindle Orientation
- Telescopic way covers
- Spindle Chiller Unit
- Flood Coolant system
- Manuals & Books
Payment Terms
A booking deposit secures the machine, with the remaining balance due prior to loading or shipment. We accept bank transfer, wire transfer, and approved payment methods.
Shipping & Logistics
We coordinate domestic and international shipping, including loading, containerization, and freight arrangements through trusted logistics partners.
Machine Inspection
Buyers can request a live video demonstration, machine inspection, or schedule an on-site visit before completing the purchase.
Export & Documentation
For international orders, we can assist with export documentation, commercial paperwork, and pre-shipment inspection requirements.
