*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Colchester |
| Model: | MultiTurn 4000 |
| Year: | 2007 |
| Equipped With: |
|---|
| Fanuc CNC Control |
| Tool Post |
| Tailstock |
| (2) Steady Rests |
| Full Enclosure |
| Coolant System |
| Work Light |
| Capacity: |
|---|
| Swing Over Bed: 21.8″ |
| Swing Over Cross Slide: 14.5″ |
| Distance Between Centers: 80″ |
| Spindle Mount: D1-11 |
| Travels: |
|---|
| X-Axis Travel: Approx. 12.0″ |
| Z-Axis Travel: Approx. 82.0″ |
| Rapid Traverse (X-Axis): Approx. 787 IPM |
| Rapid Traverse (Z-Axis): Approx. 787 IPM |
| Spindle: |
|---|
| Spindle Speed Range: 2,000 RPM |
| Headstock: 3-Speed |
| Spindle Mount: D1-11 |
| General: |
|---|
| Electrical: 230v / 3 Phase / 60 Hz |
| Machine Dimensions (Approx.): 175″ × 78″ × 75″ |
| Machine Weight (Approx.): 10,500 lbs. |
