DMG Mori DMU 50 5 Axis CNC Vertical Machining Center
Location
Rancho Cucamonga, CA
SKU
112654
Make
DMG MORI
Model
DMU 50
Year
2016
Cutting Time
5,950 Hours
Video
On Request
Out of stock
| Location: | Rancho Cucamonga, CA |
| SKU: | 112654 |
| Make: | DMG MORI |
| Model: | DMU 50 |
| Year: | 2016 |
| Cutting Time: | 5,950 Hours |
| Video: | On Request |
Add to WishlistRemove from Wishlist
Add to Wishlist
*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | DMG Mori |
| Model: | DMU 50 |
| Year: | 2016 |
| Condition: | Used – Good |
| Features: |
|---|
| Siemens 840D with CELOS CNC Control |
| 5 Axis Simultaneous Machining |
| ø 24.8″ × 19.7″ Trunnion Table |
| 15,000 RPM High Speed Spindle |
| 30 Station Automatic Tool Changer |
| Through Spindle Coolant |
| High Pressure Coolant System |
| Table Laser Sensor/Blum |
| PCMCIA Card Slot |
| Spindle Orientation |
| Helical Interpolation |
| Rigid Tapping |
| Chip Conveyor |
| Travels: |
|---|
| X – Axis: 19.7″ |
| Y – Axis: 17.7″ |
| Z – Axis: 15.7″ |
| B Axis: -35° +110° ( Table Tilt ) |
| C Axis: 360° ( Table Rotate ) |
| Rapid X Y & Z: 945 Inch Per Minute |
| Feed Rate : 945 Inch Per Minute |
| Table: |
|---|
| Table size: ø 24.8″ × 19.7″ |
| Max. Height: 31.1″ |
| Max Weight on Table: 440.9 lbs |
| Spindle: |
|---|
| Taper Size: CAT-40 |
| Speed Range: 15,000 RPM |
| Spindle Power: 20 HP |
| Automatic Tool Changer |
|---|
| Capacity: 30 Tools |
| Taper: CAT-40 |
| Max Tool Size: 3.14″ X 11.81″ |
| Max Tool Weight: 17.63 lbs. |
| General: |
|---|
| Air Required: 80 psi, 4 scfm |
| Power: 400 v / 60 hz / 34.5 kva |
| Overall Dimensions: 216.5″ x 135″ x 106″ High |
| Weight: 8818 lbs. Approx. |
Tags: DMG, DMG MORI, DMG Mori Seiki
| Travels: |
|---|
| X - Axis: 500 mm |
| Y - Axis: 450 mm |
| Z - Axis: 399 mm |
| B Axis: -35° +110° ( Table Tilt ) |
| C Axis: 360° ( Table Rotate ) |
| Rapid X Y & Z: 945 Inch Per Minute |
| Feed Rate : 945 Inch Per Minute |
| Table: |
|---|
| Table size: ø 630 mm × 500 mm |
| Max. Height: 790 mm |
| Max Weight on Table: 440.9 lbs |
| Spindle: |
|---|
| Taper Size: CAT-40 |
| Speed Range: 15,000 RPM |
| Spindle Power: 20 HP |
| Automatic Tool Changer: |
|---|
| Capacity: 30 Tools |
| Taper: CAT-40 |
| Max Tool Size: 80 mm X 300 mm |
| Max Tool Weight: 17.63 lbs. |
| General: |
|---|
| Air Required: 80 psi, 4 scfm |
| Power: 400 v / 60 hz / 34.5 kva |
| Overall Dimensions: 5,499 mm x 3,429 mm x 2,692 mm High |
| Weight: 8818 lbs. Approx. |
| Make | DMG Mori |
|---|---|
| Model | DMU 50 |
| Categories | CNC Vertical Machining Centers |
- Siemens 840D with CELOS CNC Control
- 5 Axis Simultaneous Machining
- ø 630 mm × 500 mm Trunnion Table
- 15,000 RPM High Speed Spindle
- 30 Station Automatic Tool Changer
- Through Spindle Coolant
- High Pressure Coolant System
- Table Laser Sensor/Blum
- PCMCIA Card Slot
- Spindle Orientation
- Helical Interpolation
- Rigid Tapping
- Chip Conveyor
