*All specifications are approximations and are subject to verification. Comes as shown in the images. Please call us if you have any questions before making a purchase. All sales are final.*
| Make: | Doosan |
| Model: | SVM 4100 |
| Year: | 2021 |
| Condition: | Used – Good |
| Machine Type: | CNC Vertical Machining Center |
| Country of Origin: | Korea |
-
Features:
- DOOSAN FANUC i Plus CNC Control with iHMI
- 15″ Color LCD Touchscreen Display
- Direct-Drive Spindle
- Rigid Tapping
- EZ Guide i Conversational Programming
- Adaptive Feed Control (AFC)
- Tool Load Monitoring
- Thermal Displacement Compensation
- Fully Enclosed Machining Area
-
Travels & Working Area:
- X-Axis Travel: 30.3″
- Y-Axis Travel: 16.1″
- Z-Axis Travel: 20.1″
- Spindle Nose to Table: 3.9″ – 24.0″
-
Table:
- Table Size: 36.2″ × 16.1″
- Max Table Load: 1,322 lbs
- 3 T-Slots (18H8, 4.9″ Spacing)
- T-Slot Table Surface
-
Spindle:
- Spindle Taper: BT40
- Max Spindle Speed: 12,000 RPM
- Spindle Motor: 24.8 HP (S3) / 7.4 HP (Continuous)
- Max Spindle Torque: 70.5 ft-lbs
- Direct-Drive Spindle Connection
- Sensorless Thermal Compensation
-
Feedrates & Axis Performance:
- Rapid Traverse (X/Y/Z): 1,417 IPM
- Axis Acceleration: X 0.72G / Y 0.6G / Z 0.6G
- Eco-Friendly Grease Lubrication on All Axes
-
Automatic Tool Changer:
- 30-Tool Automatic Tool Changer
- Tool Shank: BIG PLUS BT40 (Standard)
- Tool-to-Tool Time: 1.3 sec
- Chip-to-Chip Time: 3.3 sec
- Max Tool Diameter: 3.15″ (Adjacent) / 4.92″ (No Adjacent)
- Max Tool Length: 11.8″
- Max Tool Weight: 13.2 lbs
- Memory Random Tool Selection
-
Coolant System:
- Flood & Base Coolant System
- Coolant Flow Rate: 200 L/min
- Coolant Tank Capacity: 63.4 Gallons
- Through-Spindle Coolant (20 / 70 Bar – Optional)
- Programmable Flood Coolant (Optional)
- Coolant Chiller (Optional)
-
Chip Management:
- Chip Pan (Standard)
- Hinged Belt Chip Conveyor (Optional)
- Magnetic Scraper Conveyor (Optional)
- Chip Bucket: 300 L
- Air Gun & Coolant Gun
-
CNC Control:
- DOOSAN FANUC i Plus Control
- 15″ Color LCD Touchscreen (iHMI)
- Full QWERTY Keyboard
- EZ Guide i Conversational Programming
- Adaptive Feed Control
- Tool Life Management
- Tool & Workpiece Counters
- Ethernet, USB, PCMCIA & RS232C
- MTConnect & OPC UA Ready
- 4th / 5th Axis Ready
-
Electrical & Utilities:
- Power Supply: AC 220V / 3-Phase / 50–60 Hz
- Rated Power Capacity: 24.8 kVA
- Full Load Current: 65.08 Amps
- Compressed Air Supply: 0.54 MPa
- Largest Motor: 12.5 HP
-
Machine Dimensions & Weight:
- Machine Length: 85.5″
- Machine Width: 88.6″
- Machine Height: 104.8″
- Machine Weight: 8,487 lbs
