*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Fadal |
| Model: | 6535 VMC |
| Year: | 2004 |
| Features: |
|---|
| Fadal CNC Control |
| 50-Taper Spindle |
| 7,500 RPM Spindle |
| 30 HP Main Motor |
| 32-Tool Automatic Tool Changer |
| Enclosed Work Area |
| Large 5-T-Slot Worktable |
| Coolant System |
| Tool Storage / Tooling as Pictured |
| Capacity: |
|---|
| Table Size: 69″ × 35″ |
| Maximum Table Load: 4,250 lb |
| T-Slots: 5 |
| Floor-to-Table Height: 40.3″ |
| Travels: |
|---|
| X-Axis Travel: 65″ |
| Y-Axis Travel: 35″ |
| Z-Axis Travel: 35″ |
| Spindle Nose to Table: 5″–39″ |
| Rapid Traverse: 900 IPM X/Y, 700 IPM Z |
| Spindle: |
|---|
| Spindle Speed: 7,500 RPM |
| Spindle Taper: 50 Taper |
| Main Motor: 30 HP |
| Automatic Tool Changer: |
|---|
| Tool Changer Type: Automatic Tool Changer |
| Tool Changer Capacity: 32 Tools |
| Tool Change Time: 1.9 sec |
| Maximum Tool Weight: 40 lb |
| General: |
|---|
| Power Source: 220V / 3-Phase |
| Machine Weight (Approx.): 29,000 lb |
| Machine Dimensions (Approx.): 219″ W × 130″ D × 133″ H |
