*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Hyundai Kia |
| Model: | SKT-300 |
| Year: | 2008 |
| Condition: | Used – Good |
| Machine Type: | CNC Turning Center |
| Control: | Fanuc Series 0i-TC CNC Control |
| Equipped With: |
|---|
| Fanuc Series 0i-TC CNC Control |
| 14″ 3-Jaw Hydraulic Chuck |
| 12 Position Automatic Turret |
| Tool Presetter |
| Programmable Tailstock |
| Chip Conveyor |
| Coolant System |
| Automatic Lubrication System |
| Hydraulic System |
| MPG Handwheel |
| RS-232 Interface |
| Rigid Tapping |
| Thread Cutting Capability |
| Foot Pedal Chuck Control |
| Work Light |
| Heavy Duty Box Way Construction |
| 2-Speed Gearbox |
| Tooling Included |
| Accessories Included |
| Capacity: |
|---|
| Max Swing Over Bed: 29.0″ |
| Max Swing Over Cross Slide: 18.9″ |
| Max Turning Diameter: 22.0″ |
| Max Turning Length: 28.0″ |
| Distance Between Centers: 28.0″ |
| Bar Capacity: 3.5″ |
| Spindle Bore: 4.0″ |
| Travels: |
|---|
| X Axis Travel: 14.0″ |
| Z Axis Travel: 29.0″ |
| Feedrate: |
|---|
| Rapid Traverse X Axis: Approx. 787 IPM |
| Rapid Traverse Z Axis: Approx. 945 IPM |
| Spindle: |
|---|
| Spindle Nose: A2-8 |
| Spindle Bore: 4.0″ |
| Spindle Speed: 3,000 RPM |
| Spindle Motor: 30/35 HP |
| Chuck Size: 14″ |
| Turret: |
|---|
| Turret Capacity: 12 Stations |
| Turret Type: Automatic Indexing |
| Tooling Style: Bolt-On Tooling |
| Tailstock: |
|---|
| Tailstock Type: Programmable |
| Tailstock Included: Yes |
| General: |
|---|
| Power Source: 220V / 3-Phase |
| Machine Dimensions: Approx. 144″ x 84″ x 84″ High |
| Machine Weight: Approx. 12,500 – 14,000 lbs |
