*All specifications are approximations and are subject to verification. Comes as shown in the images. Please call us with any questions before purchasing. All sales are final.*
| Make: | Mazak |
| Model: | Quick Turn Nexus 350 |
| Year: | 2005 |
| Machine Type: | CNC Turning Center |
| CNC Control: | Mazatrol 640T Nexus |
| EQUIPPED WITH: |
|---|
| Mazatrol 640T Nexus CNC Control |
| 15.75″ 3-Jaw Hydraulic Chuck |
| 12-Position Automatic Tool Turret |
| Chip Conveyor |
| Coolant System |
| Fully Enclosed Machining Area |
| Hydraulic Chucking System |
| Automatic Lubrication System |
| Tool Holders Visible in Turret |
| Capacity: |
|---|
| Max Swing: 26.77″ |
| Max Turning Length: 32.37″ |
| Max Cutting Diameter: 10.39″ |
| Spindle Bore: 3.46″ |
| Chuck Size: 15.75″ |
| Travels: |
|---|
| X-Axis Travel: 8.87″ |
| Z-Axis Travel: 26.75″ |
| Spindle: |
|---|
| Maximum Spindle Speed: 4,000 RPM |
| Spindle Bore: 3.46″ |
| Turret: |
|---|
| Turret Type: Automatic Drum-Type Turret |
| Tool Stations: 12 |
| Tailstock: |
|---|
| Type: Hydraulic/Programmable Tailstock |
| Tailstock Center: Present |
| General: |
|---|
| Machine Dimensions (Approx.): 116″ L × 80″ W × 82″ H |
| Machine Weight (Approx.): 14,530 lbs. |
