*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Mori Seiki |
| Model: | NLX2500/700 |
| Year: | 2012 |
| Equipped With: |
|---|
| Mori Seiki MAPPS CNC Control |
| 12-Station Turret |
| Hydraulic Tailstock |
| Automatic Tool Presetter |
| Ethernet |
| Parts Catcher |
| Chip Conveyor |
| Mist Collector |
| Fully Enclosed Splash Guard |
| No Chuck |
| Capacity: |
|---|
| Maximum Swing Over Bed: 36.2″ |
| Maximum Swing Over Cross Slide: 29.2″ |
| Maximum Turning Diameter: 14.0″ |
| Maximum Turning Length: 27.7″ |
| Bar Capacity: 3.1″ |
| Travels: |
|---|
| X-Axis Travel: 10.2″ |
| Z-Axis Travel: 31.3″ |
| Spindle: |
|---|
| Spindle Speed: 4,000 RPM |
| Spindle Nose: A2-8 |
| Bar Capacity: 3.1″ |
| Turret: |
|---|
| Number of Stations: 12 |
| Tailstock: |
|---|
| Tailstock Type: Hydraulic |
| General: |
|---|
| Power Requirement: 220 V / 3 Phase / 60 Hz |
| Connected Load: 33 kVA |
| Machine Dimensions (Approx.): 124″ × 73″ × 80″ |
| Machine Weight (Approx.): 9,260 lbs |
