*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Okuma |
| Model: | 2SP-150H |
| Year: | 2015 |
| Equipped With: |
|---|
| Okuma OSP-P300L CNC Control |
| Dual Spindles |
| (2) 12-Position Turrets |
| (2) 16-Station Stacker Work Tables |
| (2) 18-Position Work Tables |
| Gantry Robot / Gantry Loaders |
| 8″ Chucks |
| Chip Conveyor |
| MP Systems Type AT-RT High-Pressure Coolant System |
| Automatic Part Loading and Unloading |
| Enclosed Machine Guarding |
| Capacity: |
|---|
| Maximum Turning Diameter: 5.90″ |
| Maximum Part Weight: 6.6 lb |
| Chuck Size: 8″ |
| Maximum Turning Length: 5.91″ |
| Travels: |
|---|
| X-Axis Turret Travel: 5.91″ |
| Z-Axis Turret Travel: 6.10″ |
| Rapid Traverse X/Z: 787 IPM |
| Spindles: |
|---|
| Spindle Configuration: Dual Spindle |
| Maximum Spindle Speed: 4,500 RPM |
| Spindle Nose: 140 Flat |
| Spindle Bore: 1.65″ |
| Spindle Motor: 15 HP per Spindle |
| Turret: |
|---|
| Turret Capacity: 12 Positions Each |
| Configuration: Dual Turret |
| General: |
|---|
| Machine Weight (Approx.): 11,000 lb |
| Machine Dimensions (Approx.): 85″ W × 73″ D × 103–104″ H |
