Okuma LFS15-2SP Twin Spindle CNC Turning Center

SKU 11735

Make/Model Okuma LFS15-2SP

Video On Request

Out of stock

SKU:	11735
Make/Model:	Okuma LFS15-2SP
Video:	On Request

SKU: 11735

*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*

Make:	Okuma
Model:	LFS15-2SP

Equipped With:
Okuma OSP-7000L CNC Control
Twin Opposed Spindles
Twin 12-Station Turrets
(2) 8″ Kitagawa Hydraulic Chucks
Main Spindle Collet Chuck
Sub Spindle Collet Chuck
Full Machine Enclosure
Automatic Lubrication System
Coolant System
Parts Catcher
Work Lights
Dual Channel Machining
Chip Conveyor Interface

Capacity:
Chuck Size: 8″
Main Spindle Bar Capacity: 2.05″
Sub Spindle Bar Capacity: 2.05″
Maximum Turning Diameter: 10.24″
Maximum Turning Length: 15.75″

Travels:
Upper X-Axis Travel: 7.09″
Upper Z-Axis Travel: 16.14″
Lower X-Axis Travel: 7.09″
Lower Z-Axis Travel: 16.14″

Spindle:
Main Spindle Speed: 4,500 RPM
Sub Spindle Speed: 4,500 RPM
Spindle Nose: A2-6
Main Spindle Bore: 2.44″
Sub Spindle Bore: 2.44″

Turret:
Upper Turret Stations: 12
Lower Turret Stations: 12
Turret Type: Bi-Directional Servo Indexing
Tool Shank Size: 1.00″
Boring Bar Capacity: 1.57″

General:
Country of Manufacture: Japan
Machine Dimensions (Approx.): 145″ × 86″ × 92″
Machine Weight (Approx.): 19,800 lbs

Equipped With:
Okuma OSP-7000L CNC Control
Twin Opposed Spindles
Twin 12-Station Turrets
(2) 203 mm Kitagawa Hydraulic Chucks
Main Spindle Collet Chuck
Sub Spindle Collet Chuck
Full Machine Enclosure
Automatic Lubrication System
Coolant System
Parts Catcher
Work Lights
Dual Channel Machining
Chip Conveyor Interface

Capacity:
Chuck Size: 203 mm
Main Spindle Bar Capacity: 52 mm
Sub Spindle Bar Capacity: 52 mm
Maximum Turning Diameter: 260 mm
Maximum Turning Length: 400 mm

Travels:
Upper X-Axis Travel: 180 mm
Upper Z-Axis Travel: 410 mm
Lower X-Axis Travel: 180 mm
Lower Z-Axis Travel: 410 mm

Spindle:
Main Spindle Speed: 4,500 RPM
Sub Spindle Speed: 4,500 RPM
Spindle Nose: A2-6
Main Spindle Bore: 62 mm
Sub Spindle Bore: 62 mm

Turret:
Upper Turret Stations: 12
Lower Turret Stations: 12
Turret Type: Bi-Directional Servo Indexing
Tool Shank Size: 25 mm
Boring Bar Capacity: 40 mm

General:
Country of Manufacture: Japan
Machine Dimensions (Approx.): 3,683 mm × 2,184 mm × 2,337 mm
Machine Weight (Approx.): 19,800 lbs

Categories	CNC Lathes & Turning Centers
Make	Okuma
Model	LFS15-2SP

Payment Terms

A booking deposit secures the machine, with the remaining balance due prior to loading or shipment. We accept bank transfer, wire transfer, and approved payment methods.
