*All specifications are approximations and are subject to verification. Comes as shown in the images.
Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: |
Samsung |
| Model No.: |
SL30 |
| Year of Manufacture: |
2020 |
| Condition: |
Used |
| Machine Type: |
CNC Turning Center |
| CNC Control: |
Fanuc CNC Control |
| Country of Origin: |
South Korea |
| Equipped With: |
| Heavy Duty Slant Bed Design |
| Hydraulic Tailstock |
| Fanuc CNC Control |
| 12-Station Turret |
| Chip Conveyor |
| Coolant System |
| Fully Enclosed Guarding |
| High Torque Cutting Capability |
| Capacity: |
| Max Swing Over Bed: 30.0″ |
| Max Turning Diameter: 16.0″ |
| Max Turning Length: 30.0″ |
| Bar Capacity: 3.0″ |
| Spindle: |
| Chuck Size: 12″ Hydraulic |
| Spindle Speed: 3,000 RPM |
| Spindle Bore: 3.15″ |
| Spindle Nose: A2-8 |
| Main Motor: 25 HP |
| Turret / Tooling: |
| Number of Stations: 12 |
| Tool Type: VDI / Bolt-On |
| Index Time: Fast Indexing |
| Travels: |
| X-Axis Travel: 10.0″ |
| Z-Axis Travel: 32.0″ |
| Rapid Traverse (X/Z): ~787 / 945 IPM |
| Tailstock: |
| Type: Programmable Hydraulic Tailstock |
| Quill Diameter: ~3.5″ |
| Quill Travel: ~4.0″ |
| Taper: MT-4 |
| Coolant & Chip Handling: |
| Coolant System: Yes |
| Chip Conveyor: Yes |
| Electrical: |
| Power Requirement: 220V / 3 Phase / 60 Hz |
| General: |
| Machine Weight: ~12,000 – 14,000 lbs |
