Model #: MCV-520
Condition: Unable to fully test machine, therefore we are selling it AS-IS.
- OKK-CNC MATIC-G Control.
- CAT50 Spindle Taper.
- 30-Station Automatic Tool Changer.
- Coolant System.
- Kurt Vises.
- Aluminum Sub-Plate.
Table Dimensions: 51″ x 21″
Maximum Weight on Table: 2,200 lbs.
Maximum Speed: 3,500 RPM
Spindle Center to Column: 22.5″
Spindle Nose to Table Top: 7.875″ to 29.875″
Motor: 15 Horsepower
Rapid Traverse Rate (X, Y, Z,): 472 in/min
Automatic Tool Changer:
Tool Capacity: 30
Maximum Tool Diameter: 7.875″
Maximum Tool Length: 13.75″
Maximum Weight: 33 lbs.
Tool Change Time: 3 seconds
Machine Weight: 19,000 lbs.
Electrial: 220 / 440 Volt, Three Phase
Overall Dimensions: 110″ x 150″ x 140″ tall (approx.)
USED-OKK CNC Vertical Machining Center Model MCV-520 and Comes as shown in pictures.
