*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Citizen Cincom |
| Model: | E-32 |
| Year: | 1995 |
| Equipped With: |
|---|
| Cincom 6 Axis CNC Control |
| Long Parts Capable |
| Coolant System |
| Automatic Lubrication System |
| Capacity: |
|---|
| Max Turning Diameter: 1.26″ (32 mm) |
| Max Turning Length: 12.6″ (320 mm) |
| Max Bar Capacity: 1.26″ (32 mm) |
| Tool Capacity: 20 |
| Spindle: |
|---|
| Main Spindle Index: 0.01 Degree (C-axis control) |
| Main Spindle Bore: 1.26″ (32 mm) |
| Main Spindle Speed: 6,000 RPM |
| Main Spindle Motor: 7.5 HP |
| Back Spindle Speed: 5,000 RPM |
| Back Spindle Motor: 5 HP |
| Turret: |
|---|
| Upper Turret Capacity: 10 Stations |
| Lower Turret Capacity: 10 Stations |
| Live Milling Speed: 5000 RPM |
| Live Milling Motor: 5 HP |
| Max Drilling Capability: 25/64″ (10 mm) |
| Max Tapping Capability: M8 x P1.25 |
| General: |
|---|
| Power Source: AC 220 V, Three Phase, 60 Hz |
| Overall Dimensions: 120″ x 61″ x ″ High |
| Weight: 8800 lbs Approx. |
