*All specifications are approximations and are subject to verification. Comes as shown in the images.
Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: |
Brother |
| Model No.: |
Speedio R450X1 |
| Year of Manufacture: |
2018 |
| Condition: |
Used – Good |
| Machine Type: |
CNC Vertical Machining Center (Drill & Tap) |
| CNC Control: |
Brother CNC-C00 Control |
| Equipped With: |
| Brother CNC Control |
| High-Speed BT30 Spindle |
| 22-Position Automatic Tool Changer |
| Rigid Tapping |
| Manual Pulse Generator (Handwheel) |
| Coolant System |
| Chip Conveyor (Optional / May Vary) |
| Servo Auto Door |
| Light Curtain / Safety System |
| Work Light |
| Spindle Air Blast |
| Capacity: |
| Table Size: 23.6″ × 11.8″ (600 × 300 mm) |
| Maximum Table Load: 265 – 400 lbs |
| Travels: |
| X-Axis Travel: 17.7″ (450 mm) |
| Y-Axis Travel: 12.6″ (320 mm) |
| Z-Axis Travel: 12.0″ (305 mm) |
| Spindle: |
| Spindle Taper: BT30 |
| Spindle Speed: 10,000 – 16,000 RPM |
| Spindle Motor: ~6.5 – 10 HP |
| Spindle Type: High-Speed Direct Drive |
| Tooling: |
| Tool Capacity: 22 ATC |
| Max Tool Diameter: ~3.1″ |
| Max Tool Length: ~7.9″ |
| Max Tool Weight: ~6.6 lbs |
| Tool Change Time: Tool-to-Tool: ~0.7 sec / Chip-to-Chip: ~1.5 sec |
| Feed Rates: |
| Rapid Traverse (X/Y/Z): 1,969 IPM (50 m/min) |
| Cutting Feedrate: Up to 1,181 IPM |
| Electrical: |
| Voltage: 200 / 220V |
| Phase: 3-Phase |
| Frequency: 50/60 Hz |
| General: |
| Machine Weight: ≈5,900 – 6,000 lbs |
| Floor Space: Approx. 55″ × 104″ |
| Machine Height: ≈101″ |
| Features: |
| Ultra-fast tool change (sub-second) for high productivity |
| Compact footprint with high-speed machining capability |
| Ideal for drilling, tapping, and light milling applications |
| High-speed BT30 spindle optimized for small parts production |
| Excellent for automotive, electronics, and medical components |
| Low cycle times with high acceleration and rapid rates |
| Reliable Brother CNC control for easy operation |
