*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Cincinnati Milacron |
| Model: | M10 |
| Machine Type: | CNC Turning Center |
| CNC Control: | GE Fanuc Series 21i-T |
| Equipped With: |
|---|
| GE Fanuc Series 21i-T CNC Control |
| Two 7-Position Tool Holders |
| 14 Total Tool Positions Based on Supplied Configuration |
| Chuck-Type Spindle/Workholding Arrangement |
| Chip Conveyor |
| Enclosed Machining Area |
| Hydraulic System |
| Coolant and Lubrication System Components |
| Electrical Control Cabinet |
| Capacity: |
|---|
| Chuck Size: 12″ |
| Maximum Swing Over Bed: 21.75″ |
| Maximum Turning Diameter: 12″–15″ |
| Maximum Turning Length: 20″–30″ |
| Bar Capacity: 2.5″–3.15″ |
| Spindle Bore: 3″–3.5″ |
| Distance Between Centers: 40″ |
| Boring Bar Capacity: 1.5″–2″ |
| Travels: |
|---|
| X-Axis Travel: 8″–10″ |
| Z-Axis Travel: 20″–30″ |
| Spindle: |
|---|
| Maximum Spindle Speed: 3,000–4,000 RPM |
| Spindle Motor Power: 25–35 HP |
| Spindle Nose: A2-6 |
| Chuck Diameter: 12″ |
| Turret: |
|---|
| Number of Tool Holders: 2 |
| Tool Positions per Holder: 7 |
| Total Tool Positions: 14 |
| Boring Bar Capacity: 1.5″–2″ |
| Feed Rates: |
|---|
| X-Axis Rapid Traverse: 400–600 IPM |
| Z-Axis Rapid Traverse: 600–800 IPM |
| General: |
|---|
| Power Source: 460V / 3-Phase / 60 Hz |
| Machine Dimensions (Approx.): 176″ L × 84″ W × 92″ H |
| Machine Weight (Approx.): 16,000 lbs. |
