*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Cincinnati Milacron |
| Model: | Falcon 300 |
| Machine Type: | CNC Turning Center |
| CNC Control: | Acramatic 2100 CNC Control |
| Equipped With: |
|---|
| Acramatic 2100 CNC Control |
| 12″ Diameter Chuck |
| 12-Position Turret |
| 3,000 RPM Spindle |
| 3.7″ Hole Through Spindle |
| 600 IPM Rapid Traverse |
| Tailstock |
| Fully Enclosed Work Area |
| Coolant System |
| Chip Conveyor |
| Handheld Operator Control |
| Capacity: |
|---|
| Swing Over Bed: 25.59″ |
| Distance Between Centers: 42.4″ |
| Hole Through Spindle: 3.7″ |
| Chuck Diameter: 12″ |
| Travels: |
|---|
| X-Axis Travel: 10.4″ |
| Z-Axis Travel: 40.15″ |
| Spindle: |
|---|
| Maximum Spindle Speed: 3,000 RPM |
| Spindle Bore Through Spindle: 3.7″ |
| Chuck: 12″ Diameter |
| Turret: |
|---|
| Turret Type: CNC Turret |
| Number of Positions: 12 |
| Tool Stations: 12 |
| Feedrates: |
|---|
| Rapid Traverse Rate: 600 IPM |
