Fanuc RoboDrill α-T14iA Twin Pallet Drill Tap Center

Fanuc RoboDrill α-T14iA Twin Pallet Drill Tap Center

Out of stock

On our Floor now, One Owner All Original Paint Machine. Please feel free to ask For *VIDEO* and more Pictures.

SKU: 1710
Make/Model: Fanuc Robodrill α-T14iA
Video:



SKU: 1710 Category:

Description

Fanuc RoboDrill α-T14iA Twin Pallet Drill Tap Vertical Machining Center
MakeFanuc
Model No.Robodrill α-T14iA
Serial #P975TH165
ConditionVery Good

“On our Floor now, One Owner All Original Paint Machine. Please feel free to ask For *VIDEO* and more Pictures.”

  • Fanuc RoboDrill α-T14iA Features:
  • Fanuc 16iM CNC Control
  • 14 Tools High Speed Tool Changer
  • High precision 8,000 RPM Spindle
  • Twin Pallet Changer
  • PCMCIA Card Slot
  • Expanded Memory
  • Powerful 15 hp high torque spindle motor
  • Spindle Orientation
  • RS-232 Port
  • Rigid Tapping
  • Fast Rapid Traverse Rate
  • Flood coolant with large separate coolant tank
  • Fanuc RoboDrill α-T14iA Specifications:
  • Travels:
  • X-Axis: 19.69″
  • Y-Axis: 14.96″
  • Z-Axis: 11.81″
  • Distance from Table to Spindle Nose: 5.9″ – 17.72″
  • Table:
  • Length: 25.59″
  • Width: 14.96″
  • Max Weight on Table: 440 lbs
  • Spindle:
  • Taper Size: 30
  • Speed Range: 80 – 8,000 RPM
  • Spindle Power: 7.5 kw
  • Feed rates:
  • Rapid X,Y & Z: 1889 inch/P.M
  • Cutting Feedrate: 787″ inch/ P.M
  • Automatic Tool Changer:
  • 30 Taper
  • Capacity: 14
  • Tool Change Time: 1.2 Second
  • General:
  • Air Required: 80 psi, 4 scfm
  • Power: 25kva / 205-220v / 66FLA / 3-Phase
  • Overall Dimensions: 120″ x 62″ x 88″ High
  • Weight: 6500 lbs

Fanuc RoboDrill α-T14iA Comes as Shown in Pictures….
