*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Haas |
| Model: | VF-3SSYT |
| Year: | 2014 |
| Machine Type: | 3-Axis CNC Vertical Machining Center |
| CNC Control: | Haas CNC Control |
| Cutting Time: | 9,926 Hours |
| Features: |
|---|
| Haas CNC Control |
| 12,000 RPM Inline Direct-Drive Spindle |
| CT40 Spindle Taper |
| 24+1 Side-Mount Automatic Tool Changer |
| Renishaw Probe |
| Chip Auger |
| Flood Coolant System |
| Fully Enclosed Machining Area |
| Handheld Jog Handle |
| 3-Axis CNC Configuration |
| Rotary Chuck |
| Table: |
|---|
| Table Size: 54″ × 24″ |
| Number of T-Slots: 7 |
| T-Slot Center Distance: 3.15″ |
| Maximum Table Load: 1,750 lbs. |
| Travels: |
|---|
| X-Axis Travel: 40″ |
| Y-Axis Travel: 26″ |
| Z-Axis Travel: 25″ |
| Spindle Nose to Table: 4.2″–29.2″ |
| Spindle: |
|---|
| Maximum Spindle Speed: 12,000 RPM |
| Spindle Power: 30 HP |
| Spindle Taper: CT40 |
| Maximum Torque: 90 ft-lb @ 2,000 RPM |
| Automatic Tool Changer: |
|---|
| Type: Side-Mount |
| Tool Capacity: 24+1 |
| Maximum Tool Diameter, Full: 2.5″ |
| Maximum Tool Diameter, Large: 5.0″ |
| Maximum Tool Length: 13″ |
| Maximum Tool Weight: 12 lbs. |
| Feedrates: |
|---|
| Rapid Traverse: 1,400 IPM |
| Maximum Cutting Feedrate: 833 IPM |
| General: |
|---|
| Power Source: 195–260V / 3-Phase / 50/60 Hz |
| Air Requirement: 4 SCFM @ 100 PSI |
| Shipping Dimensions (Approx.): 156″ L × 102″ W × 109″ H |
| Machine Weight (Approx.): 15,000 lbs. |
