*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Haas |
| Model No.: | VF-6/50 |
| Year of Manufacture: | 2012 |
| Machine Type: | CNC Vertical Machining Center |
| Control: | Haas CNC Control |
| Country of Origin: | USA |
| Equipped With: |
|---|
| 50 Taper Heavy-Duty Spindle |
| Side Mount Tool Changer |
| Rigid Tapping |
| Coolant System |
| Chip Auger / Conveyor |
| Full Enclosure |
| Capacity: |
|---|
| Table Size: 64″ x 28″ |
| Max Table Load: 4,000 lbs |
| Travels: |
|---|
| X-Axis Travel: 64″ |
| Y-Axis Travel: 32″ |
| Z-Axis Travel: 30″ |
| Spindle: |
|---|
| Spindle Speed: 7,500 RPM |
| Spindle Motor: 30 HP |
| Taper: CAT 50 |
| Drive Type: Gear-Driven |
| Tooling: |
|---|
| Tool Capacity: 30+1 Tools |
| Tool Changer Type: Side Mount |
| Feed Rates: |
|---|
| Rapid Traverse (X): 710 IPM |
| Rapid Traverse (Y): 710 IPM |
| Rapid Traverse (Z): 710 IPM |
| General: |
|---|
| Power Source: AC 220/480 V, 3-Phase, 50/60 Hz |
| Machine Dimensions (L x W x H): 169″ x 120″ x 130″ |
| Machine Weight: 24,000 lbs Approx. |
