*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Haas |
| Model: | SL-40TCE |
| Year: | 2005 |
| Machine Type: | CNC Turning Center |
| CNC Control: | Haas CNC Control |
| Equipped With: |
|---|
| Haas CNC Control |
| 15″ 3-Jaw Hydraulic Power Chuck |
| A2-8 Spindle Nose |
| 10-Station Bolt-On Tool Turret |
| Tailstock |
| Tailstock Tooling |
| Tool Presetter |
| Hydraulic Tailstock |
| Programmable Tailstock |
| Chip Conveyor |
| Flood Coolant System |
| Enclosed Machine Guarding |
| Rigid Tapping |
| Tool Load Monitoring |
| Automatic Lubrication System |
| High-Precision Spindle |
| Capacity: |
|---|
| Swing Over Bed: 40″ |
| Swing Over Cross Slide: 25″ |
| Maximum Turning Diameter: 25.5″ |
| Maximum Cutting Length: 44″ |
| Between Centers: 51″ |
| Travels: |
|---|
| X-Axis Travel: 17″ |
| Z-Axis Travel: 44″ |
| X-Axis Rapid Traverse: 710 IPM |
| Z-Axis Rapid Traverse: 710 IPM |
| Spindle: |
|---|
| Spindle Motor: 40 HP |
| Maximum Spindle Speed: 2,400 RPM |
| Spindle Drive: Vector Driven |
| Spindle Nose: A2-8 |
| Spindle Bore: 4.62″ |
| Bar Capacity: 4.0″ |
| Chuck Size: 15″ |
| Turret: |
|---|
| Turret Type: Bolt-On Tool Turret |
| Turret Capacity: 10 Stations |
| Tool Size: Up to 1.25″ |
| Tailstock: |
|---|
| Type: Programmable Hydraulic Tailstock |
| Taper: MT-5 |
| Tailstock Travel: 44″ |
| General: |
|---|
| Power Source: 360–480V / 3-Phase / 50/60 Hz |
| Machine Dimensions (Approx.): 150″ L × 98″ W × 86″ H |
| Machine Weight (Approx.): 26,660 lbs. |
