*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Haas |
| Model: | VF-1D |
| Year: | 2009 |
| Machine Type: | CNC Vertical Machining Center |
| Control: | Haas CNC Control |
| Features: |
|---|
| Haas CNC Control |
| 20 HP High-Torque Spindle Motor |
| 20-Station Automatic Tool Changer |
| Chip Auger |
| Air Gun |
| USB Drive |
| MPG Control |
| Rigid Tapping |
| Spindle Orientation |
| Brushless Servo Drive Motors on All Axes |
| Telescopic Way Covers |
| Work Lights |
| Travels: |
|---|
| X-Axis Travel: 20″ |
| Y-Axis Travel: 16″ |
| Z-Axis Travel: 20″ |
| Rapid Traverse Rate: 1,000 IPM |
| Cutting Feed Rate: 630 IPM |
| Spindle Nose to Table, Minimum: 4″ |
| Spindle Nose to Table, Maximum: 24″ |
| Table: |
|---|
| Table Length: 26″ |
| Table Width: 14″ |
| Number of Standard T-Slots: 3 |
| T-Slot Width: 5/8″ |
| Maximum Table Load: 1,800 lbs |
| Spindle: |
|---|
| Spindle Taper: CAT-40 |
| Spindle Speed: 7,500 RPM |
| Spindle Motor: 20 HP |
| Spindle Type: High-Torque |
| Automatic Tool Changer: |
|---|
| Tool Capacity: 20 Stations |
| Tool Changer Type: Umbrella Style |
| Maximum Tool Weight: 12 lbs |
| Maximum Tool Diameter: 3.6″ |
| Maximum Tool Length: 11″ |
| Tool Change Time: 2.2 Seconds |
| General: |
|---|
| Air Requirement: 100 PSI, 4 SCFM |
| Power: 220 VAC / 3 Phase / 50/60 Hz |
| Machine Dimensions (Approx.): 90″ × 80″ × 100″ |
| Machine Weight (Approx.): 8,000 lbs |
