*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Haas |
| Model: | VF-2DTR |
| Year: | 2004 |
| Machine Type: | CNC Vertical Machining Center |
| CNC Control: | Haas CNC Control |
| Features: |
|---|
| Haas CNC Control |
| 4th & 5th Axis Ready |
| Trunnion Table Configuration |
| Remote Jog Handle |
| Programmable Coolant (P-Cool) |
| Side-Mount Tool Changer |
| Rigid Enclosed Work Area |
| Haas Vector Dual Drive |
| 10,000 RPM Spindle |
| 20 HP Spindle Motor |
| Capacity: |
|---|
| Table Size: 36″ × 14″ |
| Maximum Table Load: 3,000 lbs. |
| Distance Spindle Nose to Table: 4″–24″ |
| Travels: |
|---|
| X-Axis Travel: 30″ |
| Y-Axis Travel: 16″ |
| Z-Axis Travel: 20″ |
| Rapid Traverse: 1,000 IPM |
| Spindle: |
|---|
| Spindle Speed: 10,000 RPM |
| Spindle Motor: 20 HP |
| Spindle Taper: CAT 40 |
| Spindle Nose to Table: 4″–24″ |
| Automatic Tool Changer: |
|---|
| Tool Magazine Capacity: 24 Stations |
| Type: Side-Mount |
| Maximum Tool Diameter: 3.5″ |
| Maximum Tool Weight: 12 lbs. |
| General: |
|---|
| Power Source: 208/230v / 3-Phase / 50/60 Hz |
| Machine Dimensions (Approx.): 88″ L × 92.5″ W × 104″ H |
| Machine Weight (Approx.): 8,000 lbs. |
