*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Kitamura |
| Model: | Mycenter-HX400iF |
| Year: | 2007 |
| Machine Type: | 4-Axis CNC Horizontal Machining Center |
| CNC Control: | Fanuc 16i-MB |
| Features: |
|---|
| 4th Axis: Full 4th Axis |
| Automatic Pallet Changer: 2-Station |
| ATC: 50-Position Automatic Tool Changer |
| Probe: Renishaw Probe |
| Coolant System: Through-Spindle Coolant |
| Chip Management: Chip Conveyor |
| Capacity: |
|---|
| Pallet Size: 15.7″ × 15.7″ |
| Maximum Pallet Load: 880 lbs. |
| Travels: |
|---|
| X-Axis Travel: 28.9″ |
| Y-Axis Travel: 24″ |
| Z-Axis Travel: 24″ |
| Spindle: |
|---|
| Spindle Speed: 13,000 RPM |
| Spindle Taper: BT40 |
| Spindle Motor: 20–25 HP |
| Automatic Tool Changer: |
|---|
| Tool Storage Capacity: 50 Positions |
| Tool Change Time: 1.0 sec. Tool-to-Tool |
| Feeds: |
|---|
| Rapid Traverse X/Y/Z: Approx. 1,969 IPM |
| General: |
|---|
| Cutting Time: 17,596 Hours |
| Power Requirement: 45 KVA |
| Machine Weight (Approx.): 28,700 lbs. |
| Machine Dimensions (Approx.): 165″ W × 105″ D × 120″ H |
