*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Mori Seiki |
| Model: | MV-40B |
| Machine Type: | 4-Axis CNC Vertical Machining Center |
| CNC Control: | YASNAC CNC Control |
| Features: |
|---|
| YASNAC CNC Control |
| 4-Axis Machining Configuration |
| 30-Station Automatic Tool Changer |
| BT-40 Taper Spindle |
| Oilmatic Spindle Oil Cooler |
| Coolant System |
| Full Enclosure |
| Automatic Tool Changer |
| Box-Way Construction |
| Enclosed Work Area |
| Automatic Lubrication System |
| Spindle Orientation |
| Rigid Tapping |
| Table: |
|---|
| Table Size: 43.3″ × 17.7″ |
| Maximum Table Load: 1,540 lbs. |
| Travels: |
|---|
| X-Axis Travel: 31.5″ |
| Y-Axis Travel: 16.1″ |
| Z-Axis Travel: 20.1″ |
| Spindle Nose to Table: 5.9″–26.0″ |
| Spindle: |
|---|
| Spindle Taper: BT-40 |
| Spindle Speed: Up to 8,000 RPM |
| Spindle Motor: 10 HP / 7.5 HP |
| Spindle Type: Vertical |
| Automatic Tool Changer: |
|---|
| Tool Changer: Automatic Tool Changer |
| Tool Capacity: 30 Stations |
| Tool Taper: BT-40 |
| Maximum Tool Length: 9.84″ |
| Maximum Tool Weight: 17.6 lbs. |
| Maximum Tool Diameter: 3.15″ |
| Feedrates: |
|---|
| Rapid Traverse X/Y: 787 IPM |
| Rapid Traverse Z: 590 IPM |
| Cutting Feedrate: 197 IPM |
| General: |
|---|
| Power Source: 220V / 3-Phase / 60 Hz |
| Machine Weight (Approx.): 13,500 lbs. |
| Overall Dimensions (Approx.): 98″ L × 89″ W × 109″ H |
