*All specifications are approximations and are subject to verification. Comes as shown in the images.
Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: |
Samsung |
| Model No.: |
MCV-500 |
| Year of Manufacture: |
2017 |
| Condition: |
Used – Good |
| Machine Type: |
CNC Vertical Machining Center |
| CNC Control: |
Fanuc 0i-MD CNC Control |
| Equipped With: |
| Fanuc CNC Control |
| 4th Axis Ready (Rotary Table Compatible) |
| 30-Position Side Mount Tool Changer |
| CAT 40 Spindle |
| Chip Conveyor / Auger |
| Coolant System |
| Through Spindle Coolant (Optional / Equipped on many units) |
| Spindle Chiller |
| Rigid Tapping |
| Manual Guide i (Conversational Programming) |
| USB / RS232 Interface |
| Capacity: |
| Table Size: 47.3″ × 20.1″ (1200 × 510 mm) |
| Maximum Table Load: 1,300 – 1,760 lbs (600 – 800 kg approx.) |
| Travels: |
| X-Axis Travel: 41.3″ (1050 mm) |
| Y-Axis Travel: 20.5″ (520 mm) |
| Z-Axis Travel: 20.5″ (520 mm) |
| Spindle: |
| Spindle Taper: CAT 40 |
| Spindle Speed: 10,000 – 12,000 RPM |
| Spindle Motor: 20 HP |
| Spindle Type: Direct Drive |
| Tooling: |
| Tool Capacity: 30 ATC |
| Max Tool Diameter: ~3″ |
| Max Tool Length: ~12″ |
| Max Tool Weight: ~15 lbs |
| Tool Change Time: ~2 sec |
| Feed Rates: |
| Rapid Traverse (X/Y/Z): 1,417 / 1,417 / 1,181 IPM |
| Cutting Feedrate: Programmable |
| Electrical: |
| Voltage: 220 / 380 / 440V |
| Phase: 3-Phase |
| Frequency: 50/60 Hz |
| General: |
| Machine Weight: ≈13,800 lbs (≈6,250 kg) |
| Floor Space: Approx. 131″ × 87″ |
| Machine Height: ≈100″ |
| Features: |
| Rigid box guideway construction for heavy-duty cutting |
| High-speed 10K–12K RPM spindle for versatile machining |
| 4th axis ready for multi-side machining capability |
| Reliable Fanuc control for easy programming and maintenance |
| Large work envelope with compact footprint |
| Through-spindle coolant capability for deep hole machining |
| Ideal for automotive, general machining, and job shop production |
