All specifications are approximations and are subject to verification.
-
Specifications:
- Capacity:
- Tonnage: 175
- Bed width/Max. Die Length: 12′ 0″
- Distance between housings: 14′ 6″
- Bending capacity: 1″ x 11′ – 10″ die
- Tonnage in fast press: 300
- Standard stroke: 12″
- Opening height : 22″
- Closed height : 10″
- Rapid advance: 85 Inch Per Min.
- Fast press: 47 Inch Per Min.
- Full tonnage press: 20 Inch Per Min.5
- Bed width/Return speed : 36 Inch Per Min.
- Fast return: 66 Inch Per Min.
- Horsepower: 60
- Housing plates: 6″
- Bed plates : 6″
-
Equipped With:
- Dual Operator Button Switch
- Foot Operated Switch
-
Equipped With:
- Dual Operator Button Switch
- Foot Operated Switch
-
General:
- Power: 480v / 3-Phase
- Overall Dimensions: 218″ X 90″ X 160″ High Assembled
- Weight: lbs
“No Charges for loading at list Price” Dismantled for shipping.
