DMG GildeMeister CTX-510 CNC Turning Center

All specifications are approximations and are subject to verification.

• DMG GILDEMEISTER CTX-510 Equipped With:

• Fanuc 32i series CNC Control
• Hydraulic Steady Rest
• 15″ 3 Jaw Hydraulic Chuck
• Auto Tool Presetter
• Hydraulic Programmable Tailstock and Quill
• USB Drive Slot
• Coolant System
• Barfeed Interface
• 12 Station Automatic Turret
• Foot Switch
• Chip Conveyor

• DMG GILDEMEISTER CTX-510 Specifications:

• Capacity:
• Max Turning Diameter: 18.3″
• Max Turning Length: 41.4″
• Max Bar Capacity: 3.05″
• Swing Over Bed: 26.77″
• Distance Between Centers: 45.27″
• X Axis Travel: 11.81″
• Z Axis Travel: 41.33″
• Rapid Traverse X Axis: 1181 IPM
• Rapid Traverse Z Axis: 1181 IPM
• Spindle Bore: 3.54″
• Spindle Speed: 0 – 3500 RPM
• Spindle Motor: 30 HP
• Turret Capacity: 12 Stations
• Turret Index Time: 0.15 Second
• Tailstock Taper: MT-4
• Tailstock  Quill Dia.: 3.97″
• Tailstock Quill Travel: 4.7″
• Tailstock Body Travel: 33.46″

• General:

• Power: 45 kva, 220v / 3-Phase
• Overall Dimensions:
• Overall Dimensions:  High with Chip Conveyor
• Weight: 16500 lbs
