*All specifications are approximations and are subject to verification. Comes as shown in the images. Please call us with any questions before purchasing. All sales are final.*
| Make: | Doosan |
| Model: | DBC-130-II |
| Year: | 2014 |
| Machine Type: | CNC Horizontal Boring & Milling Machine |
| CNC Control: | FANUC Series 31i-B |
| Features: |
|---|
| FANUC Series 31i-B CNC Control |
| 60-Station Automatic Tool Changer |
| CAT50 Tool Taper |
| Built-In B-Axis Rotary Table |
| Sangwoo Chip Conveyor, Model DB131/130-2 |
| Through-Spindle Coolant |
| Flood Coolant |
| Fully Enclosed Work Area |
| Large T-Slotted Rotary Table |
| Heavy-Duty Table-Type Boring Mill Configuration |
| Table: |
|---|
| Table Size: 70″ × 63″ |
| B-Axis Rotary Table Size: 62.99″ × 70.9″ |
| B-Axis Indexing: 0.001° |
| Maximum Table Load: 33,068 lbs. |
| Travels: |
|---|
| X-Axis Table Travel: 118.12″ |
| Y-Axis Head Vertical Travel: 78.74″ |
| Z-Axis Column Infeed Travel: 62.99″ |
| W-Axis Spindle Travel: 27.60″ |
| Spindle: |
|---|
| Spindle Diameter: 5.12″ |
| Spindle Taper: CAT50 |
| Spindle Speed Range: 5–2,500 RPM |
| Main Spindle Motor: 35 HP |
| Spindle Travel: 27.60″ |
| Automatic Tool Changer: |
|---|
| Tool Changer Capacity: 60 Positions |
| Tool Taper: CAT50 |
| Feedrates: |
|---|
| Rapid Traverse Rate: 393.7 IPM |
| Cutting Feedrate: 1–157.5 IPM |
| General: |
|---|
| Power Source: 220V / 3-Phase / 50/60 Hz |
| Machine Weight (Approx.): 94,797 lbs. |
| Machine Height (Approx.): 295.3″ x 322.8″ x 196.9″ |
