*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Kellenberger |
| Model: | 1000U |
| Year: |
| Features: |
|---|
| Universal Grinding Capability |
| 12″ Diameter × 1″ Wide Grinding Wheel |
| Workhead |
| Tailstock |
| Wheelhead |
| Hydraulic Table Traverse |
| Coolant System |
| Electrical Control Cabinet |
| Capacity: |
|---|
| Grinding Wheel Diameter: 12″ |
| Grinding Wheel Width: 1″ |
| Workhead Speed: 5 – 500 RPM |
| Maximum Grinding Length: Approx. 39″ |
| Maximum Swing: Approx. 10″ |
| Wheelhead: |
|---|
| Grinding Wheel Size: 12″ Dia. × 1″ Wide |
| Wheel Type: External Grinding Wheel |
| Table: |
|---|
| Table Type: Hydraulic Reciprocating |
| Table Swivel: Universal |
| Workhead: |
|---|
| Workhead Speed Range: 5 – 500 RPM |
| Workhead Type: Universal |
| Tailstock: |
|---|
| Tailstock: Included |
| Center Type: Live/Dead Center Compatible |
| General: |
|---|
| Machine Type: Universal Cylindrical Grinder |
| Electrical Requirement: 3-Phase |
| Machine Dimensions (Approx.): 100″ × 72″ × 72″ |
| Machine Weight (Approx.): 8,000 lbs |
