Samsung SL 25ASY CNC Turning Center – 2013, Y-Axis, Live Tooling, Fanuc Oi-TD
Out of stock
| SKU: | 11259 |
| Make/Model: | Samsung SL-25ASY |
| Year: | 2013 |
| Condition: | Used – Good |
| Video: | On Request |
Add to WishlistRemove from Wishlist
Add to Wishlist
*All specifications are approximations and are subject to verification. Comes as shown in the images.
Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Samsung |
| Model No.: | SL-25ASY |
| Year of Manufacture: | 2013 |
| Condition: | Used |
| Machine Type: | CNC Turning Center with Y-Axis & Sub-Spindle |
| CNC Control: | Fanuc Oi-TD |
| Country of Origin: | South Korea |
| Equipped With: |
|---|
| Y-Axis Milling Capability |
| Sub Spindle (Dual Spindle) |
| Live Tooling (Turn-Mill Capability) |
| Full C-Axis Control (Main & Sub) |
| 12-Station BMT Turret |
| Fanuc Oi-TD CNC Control |
| Parts Catcher |
| Tool Presetter |
| Chip Conveyor |
| Coolant System |
| Rigid Tapping |
| Box Way Construction (Heavy Duty Cutting) |
| Slant Bed Design for Chip Evacuation |
| High-Speed Live Tooling (5,000 RPM) |
| Capacity: |
|---|
| Swing Over Bed: 25.6″ (650 mm) |
| Max Turning Diameter: 14.1″ (358 mm) |
| Max Turning Length: 20.5″ (520 mm) |
| Bar Capacity: 2.6″ (66 mm) |
| Main Spindle: |
|---|
| Chuck Size: 8″ |
| Spindle Speed: 4,000 RPM |
| Spindle Motor: 20 HP |
| Spindle Nose: A2-6 |
| Sub Spindle: |
|---|
| Chuck Size: 6″ |
| Spindle Speed: 6,000 RPM |
| Spindle Motor: 10 HP |
| Spindle Nose: A2-5 |
| Travels: |
|---|
| X-Axis Travel: 9.25″ (235 mm) |
| Y-Axis Travel: 3.94″ (±1.97″) |
| Z-Axis Travel: 22.83″ (580 mm) |
| C-Axis Indexing: 0.001° |
| Rapid Traverse (X/Y/Z): 709 / 472 / 945 IPM |
| Turret / Tooling: |
|---|
| Turret Capacity: 12 Station (BMT65) |
| Live Tooling: Yes |
| Live Tool Speed: 5,000 RPM |
| Live Tool Motor: 7.5 HP |
| Construction: |
|---|
| Bed Type: 30° Slant Bed |
| Guideways: Box Ways (X/Z) |
| Electrical: |
|---|
| Power Requirement: 220V, 3 Phase |
| Power Consumption: ~45 kVA |
| General: |
|---|
| Axis: 5-Axis (X, Y, Z, C, Sub-Spindle) |
| Machine Weight: ~12,800 – 13,000 lbs |
| Floor Space: ~142″ × 76″ |
| Categories | CNC Lathes & Turning Centers |
|---|---|
| Make | |
| Model | SL-25ASY |
