*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Takisawa |
| Model: | TC-200 L3 |
| Condition: | Used – Good |
| Machine Type: | CNC Horizontal Turning Center |
| Control: | Fanuc Series 21i-TB CNC Control |
| Equipped With: |
|---|
| Fanuc Series 21i-TB CNC Control |
| 12-Station Turret |
| 8″ Hydraulic Chuck |
| Tailstock |
| Tool Set Guide / Tool Setter |
| Coolant System |
| Fully Enclosed Work Area |
| Automatic Lubrication System |
| Work Light |
| Capacity: |
|---|
| Chuck Size : 8″ |
| Maximum Turning Diameter : Approx. 10″ |
| Maximum Turning Length : Approx. 20″ |
| Bar Capacity : Approx. 2″ |
| Travels: |
|---|
| X Axis Travel : Approx. 6″ |
| Z Axis Travel : Approx. 20″ |
| Spindle: |
|---|
| Spindle Speed : Approx. 4,000 RPM |
| Spindle Nose : A2-6 |
| Spindle Bore : Approx. 2.4″ |
| Turret: |
|---|
| Turret Capacity : 12 Stations |
| Tool Size : Approx. 1″ |
| General: |
|---|
| Power Requirement : 220V / 3-Phase |
| Machine Weight : Approx. 8,000 lbs |
| Country of Origin : Japan |
