LeBlond Makino Baron-60 CNC Turning Center

SKU 11563

Make/Model LeBlond Makino Baron-60

Year 1998

Video On Request

Out of stock

SKU:	11563
Make/Model:	LeBlond Makino Baron-60
Year:	1998
Video:	On Request

SKU: 11563

*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*

Make:	LeBlond Makino
Model:	Baron-60
Year:	1998
Machine Type:	CNC Lathe / Turning Center
Control:	GE Fanuc Series 21i-T CNC Control

Equipped With:
GE Fanuc Series 21i-T CNC Control System
24″ 3-Jaw Hydraulic Chuck Unit
Jorgensen Heavy Duty Lift-Up Chip Conveyor
Torit Dust Collector / Mist Extraction System
Programmable Heavy Duty Tailstock Assembly
10-Station Heavy Duty Turret System
Slanted Bed Design for Efficient Chip Management
Fully Enclosed Safety Splash Guarding & Enclosure
Solid Steel Hardened & Ground Box Ways
Automatic Centralized Lubrication System
Flood Coolant System with High-Capacity Tank & Pump

Capacity:
Swing Over Bed: 29.5″
Maximum Machining Diameter: 25.6″
Maximum Machining Length: 120″
Chuck Size: 24″
Bar Capacity: 4.62″

Travels:
X-Axis Travel: 27″
Z-Axis Travel: 120″

Spindle:
Spindle Nose: A2-11
Spindle Bore: 4.62″
Spindle Motor: 50 HP
Spindle Speed: 1,500 RPM

Turret:
Tool Capacity: 10-Station Turret
Turret Index Time: 0.8 Seconds

Tailstock:
Tailstock Body Travel: 110″
Tailstock Quill Taper: MT #5
Tailstock Quill Travel: 6.0″

General:
Air Required: 85 psi
Power: 460v / 60 Hz / 3-Phase / 200 FLA
Overall Dimensions: 265″ L x 96″ W x 94″ High Approx.
Weight: 31,500 lbs. Approx.

Equipped With:
GE Fanuc Series 21i-T CNC Control System
610 mm 3-Jaw Hydraulic Chuck Unit
Jorgensen Heavy Duty Lift-Up Chip Conveyor
Torit Dust Collector / Mist Extraction System
Programmable Heavy Duty Tailstock Assembly
10-Station Heavy Duty Turret System
Slanted Bed Design for Efficient Chip Management
Fully Enclosed Safety Splash Guarding & Enclosure
Solid Steel Hardened & Ground Box Ways
Automatic Centralized Lubrication System
Flood Coolant System with High-Capacity Tank & Pump

Capacity:
Swing Over Bed: 749 mm
Maximum Machining Diameter: 650 mm
Maximum Machining Length: 3,048 mm
Chuck Size: 610 mm
Bar Capacity: 117 mm

Travels:
X-Axis Travel: 686 mm
Z-Axis Travel: 3,048 mm

Spindle:
Spindle Nose: A2-11
Spindle Bore: 117 mm
Spindle Motor: 50 HP
Spindle Speed: 1,500 RPM

Turret:
Tool Capacity: 10-Station Turret
Turret Index Time: 0.8 Seconds

Tailstock:
Tailstock Body Travel: 2,794 mm
Tailstock Quill Taper: MT #5
Tailstock Quill Travel: 152 mm

General:
Air Required: 85 psi
Power: 460v / 60 Hz / 3-Phase / 200 FLA
Overall Dimensions: 6,731 mm L x 2,438 mm W x 2,388 mm High Approx.
Weight: 31,500 lbs. Approx.
