*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Hyundai |
| Model: | HIT-15S |
| Year: | 1997 |
| Equipped With: |
|---|
| 8″ 3-Jaw Hydraulic Chuck |
| Parts Catcher |
| Hydraulic Tailstock |
| 8-Station Turret |
| Chip Conveyor |
| Enclosed Splash Guard |
| Tool Presetter / Tool Eye |
| Coolant System |
| Capacity: |
|---|
| Swing Over Bed: 17.32″ |
| Maximum Turning Diameter: 10″ |
| Maximum Turning Length: 19″ |
| Distance Between Centers: 25″ |
| Maximum Bar Capacity: 2″ |
| Travels: |
|---|
| X-Axis Travel: 7.1″ |
| Z-Axis Travel: 20″ |
| Rapid Traverse X/Z: 1,181 IPM |
| Spindle: |
|---|
| Spindle Speed Range: 45–4,500 RPM |
| Spindle Motor: 20 HP |
| Spindle Bore: 2.44″ |
| Spindle Nose: A2-6 |
| Chuck: 8″ |
| Turret: |
|---|
| Turret Capacity: 8 Stations |
| Turret Type: Automatic Tool Turret |
| Tailstock: |
|---|
| Quill Diameter: 3.15″ |
| Quill Taper: MT-4 |
| Quill Stroke: 5.12″ |
| Tailstock Body Travel: 19″ |
| General: |
|---|
| Machine Weight (Approx.): 9,240 lb |
| Machine Dimensions (Approx.): 100″ L × 65″ W × 70″ H |
