*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Hyundai WIA |
| Model: | L210A |
| Year: | 2012 |
| Machine Type: | CNC Turning Center |
| Control: | Hyundai WIA Fanuc i Series CNC Control |
| Equipped With: |
|---|
| 8″ 3-Jaw Chuck |
| 12-Position Automatic Turret |
| Tailstock |
| Chip Conveyor |
| Full Enclosure |
| Capacity: |
|---|
| Swing Over Bed: 21.7″ |
| Maximum Turning Diameter: 13.8″ |
| Maximum Turning Length: 16.1″ |
| Chuck Size: 8″ |
| Spindle Bore: 2.07″ |
| Travels: |
|---|
| X-Axis Travel: 8.3″ |
| Z-Axis Travel: 16.9″ |
| Rapid Traverse X/Z: 1,417 IPM |
| Spindle: |
|---|
| Spindle Speed: 4,000 RPM |
| Spindle Motor: 20 HP |
| Spindle Nose: A2-6 |
| Turret: |
|---|
| Turret Capacity: 12 Positions |
| Tool Size: 1″ OD / 1.3″ ID |
| Turret Index Time: 0.12 sec. |
| Tailstock: |
|---|
| Tailstock Taper: MT4 |
| Tailstock Quill Diameter: 2.2″ |
| Tailstock Quill Travel: Approx. 15.7″ |
| General: |
|---|
| Power Source: 220v / 3-Phase / 60 Hz |
| Machine Weight (Approx.): 9,050 lbs. |
| Machine Dimensions (Approx.): 95″ × 65″ × 74″ |
